Twin Core Battery Cable 2x35.00mm² 240A

Product Customer Reviews
Twin Core Battery Cable 2x35.00mm² 240A
Large View
A tidy and no more expensive alternative to using individual cables. Transparent outer sheath for easy positive and negative cable identification
Twin Core Battery Cable 2x35.00mm² 240A
2x35TWIN [price]
Need your Battery Cable made up with Hex crimped/soldered/heatshrink terminals?
Please click on this link: Battery Leads made to order

The Tech Spec:
  • Cross Section: 2 X 35.00mm²
  • AWG number: 2
  • Core Diameter: 9.5-9.9 Ømm
  • Current Capacity: 240 Amps per cable
  • Rated Voltage: UO/U 450/750V
  • Max Conductor Resistance @ 20ºc:0.55Ω/km
  • Conductor operating temperature: -25ºc to +85ºc
  • Nominal conductor construction: 448 x Ø0.2mm
  • Nominal Sheath Thickness: 1.3mm
  • Average Core Insulation thickness: 1.2mm
  • Outer Cable Dimensions, Height: 15mm Width: 27mm
  • Flame retardant acc. to IEC 60332-1-2V.
  • Conductor: Flexible plain coated annealed copper rope
  • Insulation: PVC type TI1
  • Sheath: PVC type TM2 Cores
  • Colours: Red-Black
  • Sheath Colour: Transparant
  • Nominal Voltage Uo/U 300/500v
  • 100% Copper Cable

Suitable in dry, humid and wet rooms, extra flexible 100% Copper

Options:
Heat Shrink: ECS CAXBPT12.7

Lead times may apply to multiple quantities
RRP Ex Tax Inc Tax
by the metre 2x35TWIN £23.20 £27.84
25M reel (pre-order) 2x35TWIN.25 £543.91 £652.69
