Twin Core Battery Cable 2x70.00mm² 485A

Product Customer Reviews
Twin Core Battery Cable 2x70.00mm² 485A
Large View
A tidy and no more expensive alternative to using individual cables. Transparent outer sheath for easy positive and negative cable identification



Twin Core Battery Cable 2x70.00mm² 485A
2x70TWIN.1 37.29
Need your Battery Cable made up with Hex crimped/soldered/heatshrink terminals?
Please click on this link: Battery Leads made to order

The Tech Spec:
  • Cross Section: 2 X 70.00mm²
  • AWG number: 000
  • Core Diameter: 13.1-13.5 Ømm
  • Current Capacity: 485 Amps per cable
  • Rated Voltage: UO/U 450/750V
  • Max Conductor Resistance @ 20ºc:0.27Ω/km
  • Conductor operating temperature: -25ºc to +85ºc
  • Nominal conductor construction: 448 x Ø0.2mm
  • Nominal Sheath Thickness: 1.6mm
  • Average Core Insulation thickness: 1.4mm
  • Outer Cable Dimensions, Height: 33mm Width: 18mm
  • Flame retardant acc. to IEC 60332-1-2V.
  • Conductor: Flexible plain coated annealed copper rope
  • Insulation: PVC type TI1
  • Sheath: PVC type TM2 Cores
  • Colours: Red-Black
  • Sheath Colour: Transparant
  • Nominal Voltage Uo/U 300/500v
Suitable in dry, humid and wet rooms, extra flexible, 100% Copper

Only 2 metres left in stock- when they are gone they are no more!
RRP Ex Tax Inc Tax
by the metre 2x70TWIN.1 £31.08 £37.29
